L&TD

    1. INTRODUCTION

• Formed in 1991
• Consist of
• 02 Production wire-line teams
• 02 Casing inspection teams
• 01 Memory team. ( in 2003)
• Personal : 21
• Engineer: 12
• Skilled worker: 9
• Perfomed
• Over 300 PLT jobs
• Over 200 Casing/tubing inspection jobs

    2. PRODUCTION LOGGING APPLICATION

       For drilling, workover & completions

• Temperature gradient
• Diagnostic packages for casing, tubing & packer leaks
• Fluid levels
• Detection of annular flow
• Corrosion monitoring

       For reservoir perfomance monitoring

• Fluid characteristics
• Water & gas breakthrough
• Thief zones
• Water & gas coning
• Pressure maintenance
• Injection/production profile monitoring

      For production technology

• Flowrate contribution from each reservoir zone
• Measuring the effectiveness of treatment programs
• Cross flow detection
• Productivity indexes
• Formation damage evaluation
• Dump flood injection rates
• Fracture monitoring
• Wellbore capacity monitoring

      Surface Systems:

• Surface SRO System
• Menmory PL system

     Downhole tools:

• Flowmeters
• Temperature
• Capacitance Water Holdup
• Quartz Pressure
• Fluid Density
• Gamma ray, Casing Collar
• Short combination PL toolstring

12 Arm Single Radius Bowspring Capacitance Array Tool (CAT)

Simultaneous measurement of sensors close to the casing circumference provides a cross-section in partially segregated   multi-phase flows

Tool Specifications

• Max Temp: 3500F
• Max press: 15000 psi
• High Sensitivity & Accuracy
• Logging Speed: 10 – 150 ft/min
• Casing diameter: 4 ½” – 9 5/8”
• Slick-Line & Wire-Line

    CASING &TUBING INSPECTION

• Corrosion assessment
• Casing deformation
• Scale evaluation
• Location of holes, cracks & splits
• Perforating maps

       CEMENT EVALUATION

• Cement map
• Bond index
• Channel behind casing
• Micro-annular

       EQUIPMENT

•  Production logging
• 04 sets ( Wireline)
• 04 sets ( Memory)
• Casing/tubing Inspection : 05 sets
• Cement Evaluation : 05 sets
• Supplied by Computalog (USA) & Sodex (UK)

      PRODUCTION LOGGING

      TUBING & CASING INSPECTION

      Typical Cases of Broken Casing in Production Wells in White Tiger Field

        CEMENT BOND LOGS
